Kompac EZ Koat 15 Web Coater

REF: BM00305

The Kompac EZ Koat Web 15 is a small footprint, roll to roll UV & Aqueous coater capable of applying coating to on demand digital labels or cut sheets up to 14.5” wide by virtually any length.  Whether digital output or offset, each job will have the visual appeal, lasting durability, protection and rub resistant finish that your customers expect!

The EZ Koat is the only UV coating system to feature Digital UV!  Environmentally friendly, Digital UV replaces outdated & potentially hazardous ballast / mercury relay systems used in curing UV coatings.

  • "One of a kind" coating solution for digital labels
  • Easy to set up & operate
  • Apply UV, aqueous, specialty coatings & primers
  • Less than 5 minute coating change & clean up with the “patented” Kompac Vac
  • Digital control panel
  • “Patent Pending” rotating UV reflector technology allows lamp to idle during set up and between job changes to decrease down time
  • Environmentally friendly
  • Variable speed & UV intensity
  • “Patented” Kompac coating unit
  • Convert to cut sheet production in minutes
  • Dedicated coating support
  • One stop shopping for coating & supplies
  • Comes standard with web unwind, web rewind and automated coating level sensor
  • “Patented” Kompac coating unit provides on-the-fly coating control & adjustment
  • No waste...contains only 2 ounces of coating in the unit
  • EZ to clean and change coatings - With the patented "Kompac Vac" and our environmentally friendly UV Klean, coating change and clean up takes 5 minutes
  • Produces the highest gloss and a perfect finish every time
  • Durable, long life, high precision rollers
  • Eliminates the need for recirculation

Web Size:  14.0" width, 12" diameter - 355mm width, 305mm diameter
UV Lamp:  Solid State - infinitely variable UV Solid State
Speed:  Up to 80 feet per minute Up to 24 meters per minute
Stock Weight:  3pt. to 20pt.  60g/m² to 500g/m²
Controls:  Adjustable speed & UV intensity
Weight:  400lbs. 181kgs.
Dimensions:  74"L x 29"W x 50"H 1.9m x .74m x 1.27m
